notification是一种出现在任务栏的提示，特别是在4.0以后notification改进了不少，本文内容都是基于4.0及4.1以后总结来的。 分类 notification有以下几种: 1>普通notification 1.内容标题 2.大图标 3.内容 4.内容附加信息 5.小图标 6.时间 2>大布局Notification 大布局notification是在android4.1以后才增加的，大布局notification与小布局notification只在‘7’部分有区别，其它部分都一致。大布局notification只有在所有notification的最上 面时才会显示大布局，其它情况下显示小布局。你也可以用手指将其扩展为大布局(前提是它是大布局)。如下图： 大布局notification有三种类型：如图1为NotificationCompat.InboxStyle 类型。图2左部为NotificationCompat.BigTextStyle。图2右部 为：NotificationCompat.BigPictureStyle 3>自定义布局notification 除了系统提供的notification，我们也可以自定义notification。如下图所示的一个音乐播放器控制notification: 如何创建notification 1>实例化一个NotificationCompat.Builder对象;如builder 2>调用builder的相关方法对notification进行上面提到的各种设置 3>调用builder.build()方法此方法返回一个notification对象。 4>实例化一个NotificationManager对象；如：manager 5>调用manager的notify方法。 注： 一个notification不必对上面所有的选项都进行设置，但有3项是必须的： 小图标, set by setSmallIcon() 内容标题, set by setContentTitle() 内容, set by setContentText() 示例代码 示例程序截图： 0>初始化部分代码 View Code 1publicclass MainActivity extends Activity implements OnClickListener { 2 3privatestaticfinalint NOTIFICATION_ID_1 = 0; 4privatestaticfinalint NOTIFICATION_ID_2 = 1; 5privatestaticfinalint NOTIFICATION_ID_3 = 2; 6privatestaticfinalint NOTIFICATION_ID_4 = 3; 7privatestaticfinalint NOTIFICATION_ID_5 = 4; 8privatestaticfinalint NOTIFICATION_ID_6 = 5; 9privatestaticfinalint NOTIFICATION_ID_7 = 6;10privatestaticfinalint NOTIFICATION_ID_8 = 7;1112privatestaticint messageNum = 0;13private Context context = this;14private NotificationManager manager;15private Bitmap icon;16privatestaticfinalint[] btns = newint[] { R.id.btn1, R.id.btn2,17 R.id.btn3, R.id.btn4, R.id.btn5, R.id.btn6, R.id.btn7, R.id.btn8,18 R.id.btn9 };1920 @Override21protectedvoid onCreate(Bundle savedInstanceState) {22super.onCreate(savedInstanceState);23 setContentView(R.layout.activity_main);24 init();25 }2627privatevoid init() {28// 获取通知服务29 manager = (NotificationManager) getSystemService(Context.NOTIFICATION_SERVICE);30// 注册监听器31for (int btn : btns) {32 findViewById(btn).setOnClickListener(this);33 }3435 icon = BitmapFactory.decodeResource(getResources(),36 R.drawable.ic_launcher);37 }3839 @Override40publicvoid onClick(View v) {41switch (v.getId()) {42case R.id.btn1:43 showNormal();44break;45case R.id.btn2:46 showBigView_Text();47break;48case R.id.btn3:49 showBigView_Pic();50break;51case R.id.btn4:52 showBigView_Inbox();53break;54case R.id.btn5:55 showCustomView();56break;57case R.id.btn6:58 backApp();59break;60case R.id.btn7:61 backScreen();62break;63case R.id.btn8:64 showProgressBar();65break;66case R.id.btn9:67 dismiss();68break;69default:70 Toast.makeText(context, "error", Toast.LENGTH_SHORT).show();71break;72 }73 }7475privatevoid dismiss() {76 manager.cancelAll();77 } 1>普通notification View Code 1privatevoid showNormal() { 2 3 Notification notification = new NotificationCompat.Builder(context) 4 .setLargeIcon(icon).setSmallIcon(R.drawable.ic_launcher) 5 .setTicker("showNormal").setContentInfo("contentInfo") 6 .setContentTitle("ContentTitle").setContentText("ContentText") 7 .setNumber(++messageNum) 8 .setAutoCancel(true).setDefaults(Notification.DEFAULT_ALL) 9 .build();10 manager.notify(NOTIFICATION_ID_1, notification);11 } 2>大布局Text类型notification View Code 1privatevoid showBigView_Text() { 2 NotificationCompat.BigTextStyle textStyle = new BigTextStyle(); 3 textStyle 4 .setBigContentTitle("BigContentTitle") 5 .setSummaryText("SummaryText") 6 .bigText( 7 "I am Big Texttttttttttttttttttttttttttttttttttttttttttt!!!!!!!!!!!!!!!!!!!......"); 8 Notification notification = new NotificationCompat.Builder(context) 9 .setLargeIcon(icon).setSmallIcon(R.drawable.ic_launcher)10 .setTicker("showBigView_Text").setContentInfo("contentInfo")11 .setContentTitle("ContentTitle").setContentText("ContentText")12 .setStyle(textStyle)13 .setAutoCancel(true).setDefaults(Notification.DEFAULT_ALL)14 .build();15 manager.notify(NOTIFICATION_ID_2, notification);16 } 3> 大布局Picture类型notificatio View Code 1privatevoid showBigView_Pic() { 2 NotificationCompat.BigPictureStyle pictureStyle = new BigPictureStyle(); 3 pictureStyle.setBigContentTitle("BigContentTitle") 4 .setSummaryText("SummaryText").bigPicture(icon); 5 Notification notification = new NotificationCompat.Builder(context) 6 .setLargeIcon(icon).setSmallIcon(R.drawable.ic_launcher) 7 .setTicker("showBigView_Pic").setContentInfo("contentInfo") 8 .setContentTitle("ContentTitle").setContentText("ContentText") 9 .setStyle(pictureStyle)10 .setAutoCancel(true).setDefaults(Notification.DEFAULT_ALL)11 .build();12 manager.notify(NOTIFICATION_ID_3, notification);13 } 4>大布局Inbox类型notification View Code 1privatevoid showBigView_Inbox() { 2 NotificationCompat.InboxStyle inboxStyle = new NotificationCompat.InboxStyle(); 3 inboxStyle.setBigContentTitle("BigContentTitle").setSummaryText( 4 "SummaryText"); 5for (int i = 0; i < 5; i++) 6 inboxStyle.addLine("news:" + i); 7 Notification notification = new NotificationCompat.Builder(context) 8 .setLargeIcon(icon).setSmallIcon(R.drawable.ic_launcher) 9 .setTicker("showBigView_Inbox").setContentInfo("contentInfo")10 .setContentTitle("ContentTitle").setContentText("ContentText")11 .setStyle(inboxStyle)12 .setAutoCancel(true).setDefaults(Notification.DEFAULT_ALL)13 .build();14 manager.notify(NOTIFICATION_ID_4, notification);15 } 5>自定义notification 效果图： 并对中间的播放按钮做了一个简单的点击处理事件(点击播放后，请关闭幕帘否则可能会看不到toast提示) View Code 1privatevoid showCustomView() { 2 RemoteViews remoteViews = new RemoteViews(getPackageName(), 3 R.layout.custom_notification); 4 Intent intent = new Intent(this, TestMusicControl.class); 5 PendingIntent pendingIntent = PendingIntent.getBroadcast(context, 0, 6 intent, 0); 7 remoteViews.setOnClickPendingIntent(R.id.paly_pause_music, 8 pendingIntent); 9 NotificationCompat.Builder builder = new Builder(context);10 builder.setContent(remoteViews).setSmallIcon(R.drawable.music_icon)11 .setLargeIcon(icon).setOngoing(true)12 .setTicker("music is playing");13 manager.notify(NOTIFICATION_ID_8, builder.build());14 } 布局文件： View Code 1 <?xml version="1.0" encoding="utf-8"?> 2 <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" 3 android:layout_width="match_parent" 4 android:layout_height="match_parent" 5 android:gravity="center_vertical" 6 android:orientation="horizontal" > 7 8 <ImageView 9 android:id="@+id/songer_pic" 10 android:layout_width="64dp" 11 android:layout_height="64dp" 12 android:src="@drawable/yan" /> 1314 <LinearLayout15 android:layout_width="fill_parent" 16 android:layout_height="fill_parent" 17 android:gravity="center_vertical" 18 android:orientation="horizontal" > 1920 <ImageView21 android:id="@+id/last_music" 22 android:layout_width="0dp" 23 android:layout_height="48dp" 24 android:layout_weight="1" 25 android:src="@drawable/music_previous" /> 2627 <ImageView28 android:id="@+id/paly_pause_music" 29 android:layout_width="0dp" 30 android:layout_height="48dp" 31 android:layout_weight="1" 32 android:src="@drawable/music_play" /> 3334 <ImageView35 android:id="@+id/next_music" 36 android:layout_width="0dp" 37 android:layout_height="48dp" 38 android:layout_weight="1" 39 android:src="@drawable/music_next" /> 40 </LinearLayout> 4142 </LinearLayout> 带进度条的notification View Code 1privatevoid showProgressBar() { 2 3final NotificationCompat.Builder builder = new NotificationCompat.Builder( 4 context); 5 builder.setLargeIcon(icon).setSmallIcon(R.drawable.ic_launcher) 6 .setTicker("showProgressBar").setContentInfo("contentInfo") 7 .setOngoing(true).setContentTitle("ContentTitle") 8 .setContentText("ContentText"); 9new Thread(new Runnable() {1011 @Override12publicvoid run() {1314int progress = 0;1516for (progress = 0; progress < 100; progress += 5) {17//将setProgress的第三个参数设为true即可显示为无明确进度的进度条样式18 builder.setProgress(100, progress, false);19 manager.notify(NOTIFICATION_ID_7, builder.build());20try {21// Sleep for 5 seconds22 Thread.sleep(2 * 1000);23 } catch (InterruptedException e) {24 System.out.println("sleep failure");25 }26 }27 builder.setContentTitle("Download complete")28 .setProgress(0, 0, false).setOngoing(false);29 manager.notify(NOTIFICATION_ID_7, builder.build());3031 }32 }).start();33 } 点击事件处理 有时候我们可能需要实现这样的功能：当新notification出现时，我们希望点击它后可直接进入应用相应的界面中去完整查看或处理此消息的功能。然后，当我们点击back按钮时返回到应用主界面而不是桌面。比如：当我们有新的短信来时，我们在任务栏中点击它后进入读信息页面，当我们读完短信后，按“返回”键回到短信的主界面，而不是手机桌面。要实现这样的功能要我们做相应的处理： 1>返回应用主界面 View Code 1privatevoid backApp() { 2 3 TaskStackBuilder stackBuilder = TaskStackBuilder.create(this); 4// Adds the back stack 5 stackBuilder.addParentStack(OtherActivity.class); 6// Adds the Intent to the top of the stack 7 Intent resultIntent = new Intent(this, OtherActivity.class); 8 stackBuilder.addNextIntent(resultIntent); 9// Gets a PendingIntent containing the entire back stack10 PendingIntent resultPendingIntent = stackBuilder.getPendingIntent(0,11 PendingIntent.FLAG_UPDATE_CURRENT);1213 Notification notification = new NotificationCompat.Builder(context)14 .setLargeIcon(icon).setSmallIcon(R.drawable.ic_launcher)15 .setTicker("backApp").setContentInfo("contentInfo")16 .setContentTitle("ContentTitle").setContentText("ContentText")17 .setContentIntent(resultPendingIntent).setAutoCancel(true)18 .setDefaults(Notification.DEFAULT_ALL).build();19 manager.notify(NOTIFICATION_ID_5, notification);20this.finish();21 } 并需要我们在配置文件中对我们用来显示详细信息的OtherActivity进行相应的配置如下： 1 <activity2 android:name="com.example.notification.OtherActivity" 3 android:label="@string/title_activity_other" 4 android:parentActivityName=".MainActivity" > 5 <meta-data6 android:name="android.support.PARENT_ACTIVITY" 7 android:value=".MainActivity" /> 8 </activity> 2>直接返回桌面 有些时候我们可能需要实现这样的功能：当我们点击notification时弹出一个稍大点的窗口来显示整个消息，这窗口的作用就是用来显示整个消息内容的，和此应用内的其它Activity都没有关系，然后当我们点击"back"后直接返回到手机桌面。要实现这样的功能我们只需要调用builder的.setContentIntent方法，然后对所要跳转到的activity在配置文件中进行一些配置： View Code 1privatevoid backScreen() { 2 Intent notifyIntent = new Intent(this, SpecialActivity.class); 3// Sets the Activity to start in a new, empty task 4 notifyIntent.setFlags(Intent.FLAG_ACTIVITY_NEW_TASK 5 | Intent.FLAG_ACTIVITY_CLEAR_TASK); 6// Creates the PendingIntent 7 PendingIntent notify_Intent = PendingIntent.getActivity(this, 0, 8 notifyIntent, PendingIntent.FLAG_UPDATE_CURRENT); 910 Notification notification = new NotificationCompat.Builder(context)11 .setLargeIcon(icon).setSmallIcon(R.drawable.ic_launcher)12 .setTicker("backScreen").setContentInfo("contentInfo")13 .setContentTitle("ContentTitle").setContentText("ContentText")14 .setContentIntent(notify_Intent).setAutoCancel(true)15 .setDefaults(Notification.DEFAULT_ALL).build();16 manager.notify(NOTIFICATION_ID_6, notification);17this.finish();18 } 配置文件： View Code
